- Two Runway Lengths (Standard or Extended)
- Single Point Air Lock Release
- Folding Ramps with Rear Chocks
- Air / Filter / Lubricator
- Converts to a Drive-Thru Lift
- Rolling Jacks Sold Separately
Product Specifications
Specification | SM18-L | SM18-EL |
---|---|---|
Max Wheelbase | 194″ | 230″ |
Rise | 68″ | 68″ |
Length Overall | 22′ 11 3/16″ | 25′ 11 3/16″ |
Width Overall | 11′ 5 3/4″ | 11′ 5 3/4″ |
Inside of Columns | 121 1/2″ | 121 1/2″ |
Between Columns | 212″ | 248″ |
Height of Columns | 6′ 5 3/4″ | 6′ 5 3/4″ |
Width of Runways | 22″ | 22″ |
Height of Runways | 7 1/2″ | 7 1/2″ |
Width Between Runways (max.) | 46″ | 46″ |
Lifting Capacity | 18,000 lbs. | 18,000 lbs. |
Motor | 2 HP | 2 HP |
Voltage Single Phase | 208v-230v | 208v-230v |
Time of Full Rise | 100 seconds | 100 seconds |
Min. Bay Size | 16’x27′ | 16’x30′ |
